24V 3000rpm Permanent Magnet Brushless DC Motor -20℃~+60℃

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Lifetime 10000h Speed 3000rpm
Shaft Length 20mm Torque 1.2Nm
Efficiency 85% Insulation Class Class B
Noise Level 50dB Operating Temperature -20℃~+60℃
Leave a Message
Product Description

Product Description:

DC Brushless Motor is an advanced electric motor technology that provides improved performance and longer life compared to traditional brushed DC motors. It features a powerful 100W output and a noise level of 50dB, which is significantly quieter than a traditional brushed motor. The motor is also well-protected, with an IP54 protection level and Class B insulation. For convenience, the motor has a shaft length of 20mm, which is ideal for most applications.

DC Brushless Motor offers superior performance compared to traditional brushed DC motors due to its advanced design. The motor is designed to run more efficiently, delivering improved power while consuming less energy. In addition, the brushless design increases motor life expectancy significantly, providing increased reliability and reduced maintenance costs. The motor is also extremely quiet, with noise levels of just 50dB, making it perfect for applications where noise must be kept to a minimum.

DC Brushless Motor is an excellent choice for various industrial and commercial applications, offering a powerful 100W output and superior protection levels. The motor's brushless design ensures improved performance, longer life, and reduced maintenance costs. In addition, its noise level of just 50dB makes it perfect for applications where a quiet operation is required. With its IP54 protection level and its 20mm shaft length, the DC Brushless Motor is the ideal choice for any application.


  • Permanent Magnet Brushless DC Motor
  • Operating Temperature: -20℃~+60℃
  • Insulation Class: Class B
  • Noise Level: 50dB
  • Efficiency: 85%
  • Shaft Length: 20mm
  • Brushless DC Electric Motor

Technical Parameters:

Property Value
Motor Type Permanent Magnet Brushless DC Motor
Shaft Diameter 6 mm
Shaft Length 20 mm
Torque 1.2 Nm
Efficiency 85%
Noise Level 50 dB
Insulation Class Class B
Protection Level IP54
Lifetime 10000 h
Weight 1.2 kg


DC Brushless Motors are widely used in numerous applications due to their ability to provide a high degree of power and efficiency. With its 6mm shaft diameter, DC Brushless Motor is a perfect choice for applications requiring a compact size and reliable performance. It has a weight of just 1.2kg and operates at a noise level of 50dB, making it an ideal choice for applications that require a quiet working environment. The 24V voltage provides a high power output while consuming less electricity, making it an economical solution for many applications.

DC Brushless Motors are commonly used in various industries such as aerospace, automotive, medical, and robotics. Its small size and lightweight make it ideal for applications where space is limited. It is also often used in applications such as machine tools, industrial robots, and electric vehicles. In addition, its efficiency and reliability make it an excellent choice for applications such as pumps, compressors, and electric motors.

DC Brushless Motors is the perfect choice for applications that require a high degree of power, efficiency, and reliability. Its compact size, low weight, low noise level, and high voltage make it ideal for a wide variety of applications. Whether you need a motor for aerospace, automotive, medical, robotics, or other applications, the DC Brushless Motor is the perfect choice.


Customized DC Brushless Motor

Shaft Length: 20mm
Efficiency: 85%
Motor Type: DC Brushless
Lifetime: 10000h
Insulation Class: Class B

Our customized DC brushless motor is a high-performance, permanent magnet brushless dc motor that offers superior performance and durability. It features a 20mm shaft length and an efficiency rating of 85%. It has a class B insulation and has been tested to last for 10000h.


  • Q: What is a DC Brushless Motor? A: A DC brushless motor is an electronically controlled motor that uses permanent magnets to generate torque and rotation.
  • Q: What are the advantages of a DC brushless motor? A: DC brushless motors are more reliable, efficient, and quieter than traditional DC motors with brushes. They also require less maintenance.
  • Q: How does a DC brushless motor work? A: A DC brushless motor operates using a combination of magnets and electronic commutation. The permanent magnets create a rotating force, while the electronic commutation controls the direction of that rotation.
  • Q: What is the speed range of a DC brushless motor? A: The speed range of a DC brushless motor is typically between 3000 and 7000 RPM, depending on the model.
  • Q: Are DC brushless motors powerful? A: Yes, DC brushless motors are very powerful and can produce high torque outputs.
